Details
Shaped by the wind and crafted with Swiss precision, the BMC Teammachine R 01 is built for peak performance. Aerodynamic, lightweight, and engineered for speed.
Racing Redefined: The Ultimate race bike. From the cobbled Classics to one-day races, stage races, and criteriums, the Teammachine R 01 FOUR is built to win them all. Engineered in partnership with Red Bull Advanced Technologies, our Impec lab has meticulously designed the Teammachine R 01 to go beyond the limits of a typical race bike. Lightweight for conquering the steepest climbs, aerodynamically optimized to slice through the wind, and engineered with pro-level stiffness, it ensures exceptional power transfer for unmatched performance on the road. Equipped with a perfectly tuned Shimano Ultegra Di2 groupset, a precise 4iiii powermeter, the seamless ICS Aero Carbon one piece cockpit, and ultra-fast CR 50 SL wheels, the Teammachine R 01 FOUR delivers an unparalleled racing experience. Redefine speed and elevate your cycling to a whole new dimension.
Halo Fork
The ultrawide fork legs are unlike anything else seen in the peloton and help keep turbulent air, created by the front wheel, away from the frame.
The ICS Carbon Aero Cockpit
The ICS Carbon Aero Cockpit, with its progressive and aerodynamic shape, is the perfect match for this bike. Featuring a narrow top width, allowing an efficient aero position with a greater width at the drops providing incredible control at high speed.
Deep Bottom Bracket Area
We call it the “Mariana Bottom Bracket” because it’s the deepest bottom bracket we have ever made on a road bike and this perfectly optimizes the surface area for cleaner airflow.
All-New Seatpost
The new seatpost is slimmer, deeper, more compliant, and lighter than ever. With the new seatpost clamp mechanism now easier to access and maintain, including an integrated number plate holder making it the smartest way to get race-ready.
System Weight Limit: 110kg
Frame Size | 47 | 51 | 54 | 56 | 58 | 61 |
---|---|---|---|---|---|---|
Rider Height (cm) | <166 | 166-174 | 172-180 | 178-186 | 184-192 | >190 |
Reach (mm) | 367 | 377 | 386 | 392 | 402 | 409 |
Stack (mm) | 505 | 529 | 549 | 564 | 582 | 608 |
Bar Drop (mm) | 135 | 135 | 135 | 135 | 135 | 135 |
Bar Reach (mm) | 77 | 77 | 77 | 77 | 77 | 77 |
Bar Width (mm) | 360/420 | 360/420 | 360/420 | 360/420 | 360/420 | 360/420 |
BB Drop (mm) | 69 | 69 | 69 | 69 | 69 | 69 |
Crank Length (mm) | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
Fork Length (mm) | 367 | 367 | 367 | 367 | 367 | 367 |
Fork Rake (mm) | 48 | 48 | 43 | 43 | 43 | 43 |
Front Center (mm) | 568 | 586 | 589 | 599 | 614 | 630 |
Head Tube (mm) | 108 | 133 | 149 | 165 | 184 | 211 |
Head Tube Angle | 71.5° | 71.5° | 72.3° | 72.3° | 72.3° | 72.3° |
Rear Center (mm) | 410 | 410 | 410 | 410 | 410 | 410 |
Seat Angle | 74° | 74° | 73.5° | 73.5° | 73° | 73° |
Seat Tube (mm) | 418 | 463 | 499 | 519 | 541 | 570 |
Seatpost Length (mm) | 335 | 335 | 385 | 385 | 405 | 405 |
Seatpost Offset (mm) | 10 | 10 | 10 | 10 | 10 | 10 |
Standover Height (mm) | 721 | 755 | 781 | 799 | 813 | 836 |
Stem Angle | -15° | -15° | -15° | -15° | -15° | -15° |
Stem Length (mm) | 90 | 100 | 100 | 110 | 110 | 120 |
Top Tube (mm) | 515 | 532 | 552 | 562 | 582 | 598 |
Trail (mm) | 63 | 63 | 63 | 63 | 63 | 63 |
Wheelbase (mm) | 968 | 986 | 989 | 999 | 1015 | 1030 |
Specs
Frame | Teammachine R 01 Premium Carbon with Aerocore Design | ICS Technology Stealth Cable Routing | Stealth Dropout Design | Flat Mount Disc | 12 x 142mm Thru-Axle |
---|---|
Fork | Teammachine R 01 Premium Carbon | ICS Technology Stealth Cable Routing | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle |
Rims | CR 50 SL Carbon | Tubeless Ready | 50mm |
Hubs | TXC-812 & TXC-240 Centerlock |
Tires | Pirelli P Zero Race TLR | 26mm |
Bottom Bracket | SHIMANO Press Fit SM-BB72 |
Crankset | SHIMANO Ultegra (FC-R8100) |
Chainrings | 52-36T |
Shifters | SHIMANO Ultegra Di2 (ST-R8170) |
Front Derailleur | SHIMANO Ultegra Di2 (FD-R8150) |
Rear Derailleur | SHIMANO Ultegra Di2 (RD-R8150) |
Cassette/Freewheel | SHIMANO Ultegra (CS-R8101) |
Chain | SHIMANO CN-M8100 |
Rotors | SHIMANO Ultegra 160mm (RT-CL800) |
Brake Levers | SHIMANO Ultegra (BR-R8170) |
Handlebars | ICS Carbon Aero | One-Piece Full Carbon Cockpit | 135mm drop, 77mm reach, 12.5° flare |
Seatpost | Teammachine R 01 Premium Carbon Seatpost | 10mm Offset |
Pedals | Sold Separately |
Saddle | Selle Italia SLR Boost Superflow | TI316 Rail | 145mm |
Extras | 4iiii Precision Gen3+ Power Meter (Non-Drive Side), Aerocore Bottle Cages |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Anthracite / Carbon / 47cm / 700c | 07630906521380 | 30006847 | 210000095633 |
Anthracite / Carbon / 51cm / 700c | 07630906521373 | 30006848 | 210000095634 |
Anthracite / Carbon / 54cm / 700c | 07630906521366 | 30006849 | 210000095635 |
Anthracite / Carbon / 56cm / 700c | 07630906521458 | 30006850 | 210000095636 |
Anthracite / Carbon / 58cm / 700c | 07630906521540 | 30006851 | 210000095637 |
Anthracite / Carbon / 61cm / 700c | 07630906521533 | 30006852 | 210000095516 |
